Philips Achieva 1.5T-SN 21177-YOM MRI. Philips MRI Achieva 1.5T-SN 21177-YOM 2006 Year: 2006.

Additional Details

Philips MRI Achieva 1.5T-SN 21177-YOM 2006
INSPECTION DATE: 19/07/2024
SYSTEM INFORMATION
Manufacturer and model: PHILIPS ACHIEVA
System model no.: 781196
System serial no.: 21177
System YOM: APPROX 2006
Gradient type: COPLEY 281+
Number of Channels: 8
MAGNET INFORMATION
Magnet YOM: APPROX 2006
Magnet model no.: F2000
Magnet serial no.: 808646
MAGNET INFORMATION
Current helium level: 47%
Magnet pressure: 30mBar
Shield temperature: N/A
COOLING SYSTEM INFORMATION
Compressor model no.: SUMITOMO HC-8E
Compressor YOM: APPROX 2006
Compressor running hours: N/A
Compressor pressure level: 300PSI STATIC
Last adsorber replacement: FEBRUARY 2022
Cold-head model no.
SUMITOMO 10K
Cold-head YOM: APPROX 2006
Last cold-head replacement: SERVICED FEBRUARY 2022
PATIENT TABLE INFORMATION
Table model no.: MT
Table serial no.: N/A
Table YOM: 2006
Extra trolley available? NO
Positioning pads incl.? YES
CONSOLE AND WORKSTATION(S) INFORMATION
Console model no.: HP XW8400
Console serial no.: CZC81427Q1
Console software version: R2.6.3.9
Console software options: SEE BELOW
ACCESSORIES, MANUAL HARD-COPIES AND SOFTWARE DISCS
Software and manuals (list)
MANUALS. NO SOFTWARE
Any additional items/accessories? PATIENT HEADPHONES
MAINTENANCE
Any major part replacements? RF AMP CHANGED APR 2022
Is system logbook present? YES
COILS
Coil name & channels: Model no.: Serial no.: Test result
FLEX S: 452213219877: ON300125026: NOT TESTED
FLEX M: 452213231178: 486: NOT TESTED
SYNERGY SPINE: 452213219877: 00005: NOT TESTED
SENSE HEAD: 453530057611: 2271: NOT TESTED
SENSE KNEE: 453530056073: 58076: NOT TESTED
SYNERGY BODY COIL: 459800051892: 000047: NOT TESTED
FLEX L: 452213317151: 00140: NOT TESTED
PHANTOMS
Model name: Amount: Model no.: Serial no.
QA TESTING
Result: Date of test
Daily QA Test result:
Pictures of (To be taken and sent to internal sales team separately):
Components: Completed (Y/N): Notes
Magnet: Y
Helium Level: Y
Compressor: Y
Coils:
Options: Y
Software rev: Y
Cooling Status: Y
Overall system
GantrYY
Table: Y
Console: Y
Workstations: Y
Cabinets: Y
Accessories:
Software: N, Non-PRESENT
Manuals: Y
Other Accessories: Y
Images:
QA results: N, NO SCANNING POSSIBLE
Covers:
Any cosmetic damages: Y, TABLETOP
