FMT System
Cost-Effective Imaging Solution
The DEL MEDICAL FMT System provides an economical, space-saving floor-mounted radiography setup—ideal for small radiology suites, imaging centers, and orthopedic clinics. Its sturdy 10 ft (3 m) floor rail ensures smooth longitudinal travel and quick positioning; 8 ft (2.4 m) and 12 ft (3.7 m) rails are also available.
Crafted to deliver reliable performance without breaking the budget, the FMT System is manufactured in the USA to guarantee years of consistent, high-quality imaging and user satisfaction.
Simple and Precise Imaging
Digital Angulation Readout
The FMT tube stand is equipped with an easy-to-read digital angulation display. You’ll see SID measurements clearly at 40 in (102 cm) or 72 in (183 cm) from the wallstand, or 40 in (102 cm) from the table. Fingertip controls and strong magnetic locks guarantee exact tube head placement. With a minimum ceiling requirement of just 7 ft 3 in (221 cm), it’s one of the lowest-profile systems in the industry.
Four-Way Float Top Table
RT100 Table
The RT100 table holds up to 700 lbs (318 kg) and features a stain-resistant tabletop that glides smoothly on precision roller bearings. Movements lock and unlock via a heavy-duty electric foot treadle, ensuring effortless, controlled adjustments.
Its standard cassette tray fits both 14 × 17 in (35 × 43 cm) and 17 × 17 in (43 × 43 cm) detectors. Built with an all-steel frame and welded base, the RT100 delivers unmatched durability. Plus, the base can house Anthem generator electronics—perfect for compact installations.
RT100 & Accessories →
Ergonomic Wall Stand
VS100 Upright Wall Stand
The compact VS100 upright incorporates an electric lock-release handle and dual counterweight cables for enhanced safety. With 58 in (148 cm) of vertical travel, it accommodates everything from skull imaging to weight-bearing knee and ankle exams while maintaining an ergonomic, space-saving profile.
VS100 Wall Stand →
Rotating Tray (Optional)
One-Handed Detector Rotation
The rotating tray makes portrait-to-landscape rotation of the DR detector effortless—no removal required. Fully extended steel slides lock securely to protect the detector during loading and unloading. Designed for ISO 14 × 17 in (35 × 43 cm) panels, it ensures quick, stable operation in both table and wall stand modes.
Technical Specifications
| Specification | Value |
|---|---|
| Minimum Ceiling Height | 87 in (221 cm) |
| Column Height | 85.5 in (217 cm) |
| Total Vertical Travel | 64.5 in (164 cm) |
| Longitudinal Travel | 96 in (244 cm) |
| Transverse Travel | 11 in (28 cm) |
| Floor-to-Focal Spot (Standard Mount) | Min: 10 in (25.4 cm); Max: 74.5 in (190 cm) |
| Rail Length Options | 10 ft (3 m) standard; optional 8 ft (2.4 m) or 12 ft (3.7 m) |
| Column Rotation | 180° (where installation allows) |
| Tube Rotation | ±180° (Detents for lateral decubitus) |
| Base-to-Rear Wall | 12 in (30.5 cm) |
| Tube/Collimator/Cable Capacity | 88 lbs (40 kg) |
| Net Weight | 200 lbs (91 kg) (excludes tube, collimator, counterweights) |
| Power Requirements | 120 VAC or 230–240 VAC 50/60 Hz |
| Optional Accessories |
– Manual collimator – 8 ft or 12 ft floor plates – DAP (Dose Area Product) meter – Full system integration (with or without generator control) |
